Mode-field matching fiber array converts the optical modes from standard single mode to customer defined mode size along the fiber transmission dir- ection. The mode converted fiber is placed into high-precision V- groove and assembled with special epoxy and unique technology. The fiber core pitch and end face angle is accurate.

• Accurate fiber core pitch
• Excellent environmental stability and reliability
• Low insertion loss
• Mode field diameter conversion from 10um to 3~5um
• Accurate polishing angle
• Customization acceptable
• ROHS and REACH compliant

• Multi-channel integrated micro-optics device
• High speed optical transceiver
