Introduction
The 90° bending fiber array is made of high-precision V-groove, special epoxy and metal housing. The fiber is bent 90° and fixed by a metal housing. The
product height is less than 3.8mm.
Features
- Accurate fiber core pitch
- Up to 16 channels
- Excellent environmental stability and reliability
- Low insertion loss
- Fiber bent 90°
- Accurate polishing angle
- Customization acceptable
- ROHS and REACH compliant
Application
- Multi-channel integrated micro-optics devices
- High speed optical transceiver
- Silicon photonics chip coupling
